Trip Switch
>>
Components [09/2014 - 01/2023]
Components [09/2014 - 01/2023]
Fig 1: Trip Switch Replacement Components [09/2014 - 01/2023]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
HOOD LOCK CONTROL LEVER SUB-ASSEMBLY
*2
LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY
*3
NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
*4
TRIP SWITCH
