Components [10/2017 - 10/2020]
Fig 1: Luggage Compartment Door Opener Main Switch Replacement Components With Torque Specifications [10/2017 - 10/2020] (1 Of 2)
| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | NEGATIVE AUXILIARY BATTERY TERMINAL | *2 | LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY |
| Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | - | - |
Fig 2: Luggage Compartment Door Opener Main Switch Replacement Components With Torque Specifications [10/2017 - 10/2020] (2 Of 2)
| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | GLOVE COMPARTMENT DOOR ASSEMBLY | *2 | GLOVE COMPARTMENT DOOR PAD PLATE |
| *3 | INSTRUMENT SIDE PANEL LH | *4 | INSTRUMENT SIDE PANEL RH |
| *5 | LOWER INSTRUMENT PANEL FINISH PANEL ASSEMBLY | *6 | LOWER NO. 1 INSTRUMENT PANEL PAD SUB-ASSEMBLY |
| *7 | LOWER NO. 2 INSTRUMENT PANEL AIRBAG ASSEMBLY | *8 | LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY |
| *9 | NO. 2 CONSOLE UPPER PANEL GARNISH | *10 | NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY |
| Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | - | - |
