Removal [12/2017 - ]: Procedure

  1. REMOVE LUGGAGE COMPARTMENT DOOR OUTSIDE GARNISH SUB-ASSEMBLY

    Refer to REMOVAL [12/2017 - ]

  2. REMOVE LICENSE PLATE LIGHT ASSEMBLY
    1. Disconnect the connector.
      GTY811672Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Detach the claw and remove the license plate light assembly.
      GTY829393Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      Remove in this Direction
