Components [01/2017 - 05/2023]

Fig 1: Clock Replacement Components With Torque Specifications (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*1	NO. 2 DECK BOARD	*2	NEGATIVE AUXILIARY BATTERY TERMINAL
	Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping" : Nm (kgfcm, ft.*lbf)	-	-

Fig 2: Clock Replacement Components (2 Of 2)

CLOCK ASSEMBLY
