Installation [04/2020 - ]: Procedure

1. Install the rear suspension tower damper assembly with the 2 nuts.

   Torque: 39 N.m (398 kgf/cm, 29 ft.lbf)

   NOTE:

   Do not compress or extend the rear suspension tower damper assembly.

   HINT:

   Make sure to install the suspension tower damper with the label facing front of the vehicle.

   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

   *a	Label
   	front of the Vehicle

Refer to INSTALLATION [03/2017 - ]
