Home >> Lexus >> 2021 >> LC 500 2D Coupe >> Repair and Diagnosis >> Brakes >> Parking Brake System >> Electric Parking Brake System - Diagnostic Codes & Symptom Tests (Coupe) >> Electric Parking Brake System >> DTC C13A2/22: Engine / Power Switch Malfunction [03/2017 - 09/2018] >> Wiring Diagram

DTC C13A2/22: Engine / Power Switch Malfunction [03/2017 - 09/2018]: Wiring Diagram

GTY832745

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
