Components [04/2013 - 09/2020]

Fig 1: Front Pillar Upper Cover Replacement Components [04/2013 - 09/2020] (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*A	for Driver Side	*B	for Front Passenger Side
*1	COURTESY LIGHT ASSEMBLY	*2	FRONT DOOR ARMREST COVER
*3	FRONT DOOR INNER GLASS WEATHERSTRIP	*4	FRONT DOOR INSIDE HANDLE BEZEL PLUG
*5	FRONT DOOR NO. 1 STIFFENER CUSHION	*6	FRONT DOOR TRIM BOARD SUB-ASSEMBLY
*7	MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL	*8	POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL

Fig 2: Front Pillar Upper Cover Replacement Components [04/2013 - 09/2020] (2 Of 2)

FRONT DOOR FRONT LOWER FRAME UPPER COVER

FRONT DOOR LOWER FRAME BRACKET GARNISH
