Components [10/2018 - 10/2019]

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2024 Lexus UX 250h, 2023 Lexus UX 250h, 2022 Lexus UX 250h, 2021 Lexus UX 250h, and 2020 Lexus UX 250h. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Coolant Replacement Components [10/2018 - 10/2019]
GTY792293Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 REAR ENGINE UNDER COVER LH *2 RESERVE TANK CAP
*3 RADIATOR DRAIN COCK PLUG - -
