Components [03/2017 - ]

Fig 1: Headup Display Replacement Components With Torque Specifications (1 Of 3)
GTY790287Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 NO. 2 DECK BOARD *2 NEGATIVE BATTERY TERMINAL
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping" : N*m (kgf*cm, ft.*lbf) - -
Fig 2: Headup Display Replacement Components (2 Of 3)
GTY1171893Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 METER MIRROR SUB-ASSEMBLY -
Fig 3: Headup Display Replacement Components (3 Of 3)
GTY783599Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 NO. 1 COMBINATION METER MIRROR PLATE *2 COMBINATION METER MIRROR ECU
