Fail-Safe Chart [06/2018 - ]

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2024 Lexus ES 300h, 2023 Lexus ES 300h, 2022 Lexus ES 300h, 2021 Lexus ES 300h, and 2020 Lexus ES 300h. However, it is still accessible from the selected car via links, so may be relevant.
  1. FAIL-SAFE FUNCTION
    1. When a malfunction occurs in the tire pressure warning system, the tire pressure warning light illuminates after blinking for 1 minute to inform the driver of the system failure.
    2. As a result of this, tire pressure monitoring is disabled and a DTC is stored in the tire pressure warning ECU and receiver.
    3. When there is a system malfunction, the value of each related tire is not displayed.
      Fig 1: Fail-Safe Function
      GTY775600Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      *a Example
