Components [10/2017 - 09/2020]
WARNING: This page does not describe the selected car, but rather 14 other vehicles, including the 2024 Lexus IS 350, 2024 Lexus IS 300, 2023 Lexus IS 350, 2023 Lexus IS 300, and 2022 Lexus IS 350. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Camshaft Oil Control Valve (For Exhaust Side Of Bank 1) Replacement Components With Torque Specifications [10/2017 - 09/2020]
| *A | for 2WD | *B | for AWD |
| *1 | CAMSHAFT TIMING GEAR BOLT | *2 | COOL AIR INTAKE DUCT SEAL |
| *3 | ENGINE UNDER COVER | *4 | INLET NO. 1 AIR CLEANER |
| N.m (kgf/cm, ft.lbf): Specified torque | - | - |
