IS 300 F Sport
>>
Repair and Diagnosis
>>
Body & Frame
>>
Exterior Body Panels
>>
(Door / Hatch) - Service Information (2 Of 2)
>>
Luggage Compartment Door Opener Inner Switch
>>
Components [09/2020 - ]
Components [09/2020 - ]
Fig 1: Luggage Compartment Door Opener Inner Switch Replacement Components [09/2020 - ]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
HOOD LOCK CONTROL LEVER SUB-ASSEMBLY
*2
LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY
*3
LUGGAGE COMPARTMENT DOOR OPENING SWITCH ASSEMBLY
*4
NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
