Components [08/2019 - ]

Fig 1: Performance Damper Replacement Components With Torque Specifications
GTY957337Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 MAIN MUFFLER HEAT INSULATOR *2 SUSPENSION TOWER DAMPER
N*m (kgf*cm, ft.*lbf): Specified torque - -
