Installation








LIGHTING (INT): ROOM LIGHT: INSTALLATION

INSTALLATION

1. INSTALL SPOT LIGHT ASSEMBLY
(a) Connect the connector.





(b) Engage the 2 guides.
(c) Engage the 2 clips and install the spot light assembly.
