Reverse Shift-linked Function of Power Mirrors does not Operate: Wiring Diagram

WARNING: This page is about a different car, the 2008 Lexus IS F. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Park/Neutral Position Switch - Wiring Diagram
G05756191Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
