Tire Pressure Warning Reset Switch: Components

WARNING: This page is about a different car, the 2008 Lexus IS F. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Tire Pressure Warning Reset Switch Replacement Components
G05752515Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
