Radio Antenna Cord: Components

WARNING: This page is about a different car, the 2008 Lexus IS F. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Radio Antenna Cord Components (1 Of 9)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Radio Antenna Cord Replacement Components (2 Of 9) with Torque Specifications

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: Radio Antenna Cord Replacement Components (3 Of 9) with Torque Specifications

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: Radio Antenna Cord Replacement Components (4 Of 9) with Torque Specifications

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 5: Radio Antenna Cord Replacement Components (5 Of 9) with Torque Specifications

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 6: Identifying Radio Antenna Cord Components (6 Of 9)

Fig 7: Radio Antenna Cord Replacement Components (7 Of 9) with Torque Specifications

Fig 8: Identifying Radio Antenna Cord Components (8 Of 9)

Fig 9: Radio Antenna Cord Replacement Components (9 Of 9) with Torque Specifications
