Rear Seat Assembly: Installation

WARNING: This page is about a different car, the 2008 Lexus IS F. However, it is still accessible from the selected car via links, so may be relevant.

INSTALL REAR SEATBACK ASSEMBLY
1. Place the seatback in the cabin.
  NOTE: Be careful not to damage the vehicle body.
2. Engage the 3 hooks.
3. Install the rear seatback assembly with the 4 bolts.
  Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf)

  Fig 1: Identifying Rear Seatback Assembly Bolts And Hooks
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
4. Pass the seat belt through the rear seat shoulder belt guide RH
5. Engage the 2 claws and close the 2 caps of the rear seat shoulder belt guide RH.

  Fig 2: Locating Claws Of Rear Seat Shoulder Belt Guide RH
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
6. Pass the seat belt through the rear seat shoulder belt guide LH.
7. Engage the 2 claws and close the 2 caps of the rear seat shoulder belt guide LH.
INSTALL REAR SEAT HEADREST ASSEMBLY RH
INSTALL REAR SEAT HEADREST ASSEMBLY LH
INSTALL REAR SEAT CUSHION ASSEMBLY
1. Engage the 2 rear hooks of the seat cushion to the child restraint seat anchor bracket
2. Engage the 2 front hooks of the seat cushion to the vehicle body
3. Confirm that the seat cushion is firmly installed
  NOTE: When installing the seat cushion, make sure the seat belt buckle is not under the seat cushion.

  Fig 4: Identifying Front Hooks Of Seat Cushion
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
