DTC P0A0F-238 Engine Failed to Start: Description

The HV control ECU detects this DTC and effects fail-safe control if the engine or transaxle gear has seized up, or foreign objects have been caught in either of them.

DTC DETECTION CONDITION AND TROUBLE AREA

DTC No.	INF Code	DTC Detection Condition	Trouble Area
P0A0F	238	Engine does not start even though cranking it (transaxle input malfunction [engine system])	Engine Hybrid vehicle transaxle assembly (shaft, gear) Transmission input damper Wire harness or connector HV control ECU

HINT:

If this DTC is output, the engine or transmission gear may be seized up. Be sure to check the level of the engine oil, transaxle oil (ATF), and coolant (for Inverter) before inspection.

Fig 1: Engine Failed To Start System Diagram
