Steering Pad: Removal

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.

Fig 1: Identifying Steering Pad Contact Plate
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
REMOVE NO. 3 STEERING WHEEL COVER LOWER
1. Using a screwdriver, remove the No. 3 steering wheel cover lower.
  HINT:

  Tape the screwdriver tip before use.

  Fig 2: Removing Steering Wheel No.3 Cover Lower
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
REMOVE NO. 2 STEERING WHEEL COVER LOWER
1. Using a screwdriver, remove the No. 2 steering wheel cover lower.
  HINT:

  Tape the screwdriver tip before use.

  Fig 3: Removing Steering Wheel No.2 Cover Lower
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
REMOVE STEERING PAD
1. Using a T30 "TORX" socket wrench, loosen the 2 "TORX" screws until the groove along the screw circumference catches on the screw case.

  Fig 4: Locating Steering Pad Torx Screws
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Pull out the steering pad from the steering wheel assembly and support the steering pad with one hand as shown in the illustration.
  NOTE: When removing the steering pad, do not pull the airbag wire harness.
3. Disconnect the horn connector.
4. Disconnect the 2 connectors and remove the steering pad.
  NOTE: When handling the airbag connector, take care not to damage the airbag wire harness.

  Fig 5: Locating Horn Connectors
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
