DTC P3207-753 Short to GND in Rear Guard Sensor 2 Connection; DTC P3208-754 Open or Short to B+ in Rear Guard Sensor 2 Connection: Wiring Diagram

Fig 1: Short To GND In Rear Guard Sensor 2 Connection - Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
