Automatic Transmission Unit: Components

WARNING: This page is about a different variant/trim than selected.

Fig 1: Automatic Transmission Unit Components With Torque Specifications (1 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Automatic Transmission Unit Components With Torque Specifications (2 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: Automatic Transmission Unit Components With Torque Specifications (3 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: Automatic Transmission Unit Components With Torque Specifications (4 Of 5)

Fig 5: Automatic Transmission Unit Components With Torque Specifications (5 Of 5)
