DTC P0011, P0012, P0021, P0022: Camshaft Position "A" -Timing Over-Advanced Or System Performance (Bank 1)/(Bank 2), Camshaft Position "A" -Timing Over-Retarded (Bank 1)/(Bank2): Wiring Diagram

Fig 1: Camshaft Position Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
