DTC C1232/32, C1243/43, C1244/44, C1245/45: Deceleration Sensor Does Not Function; Malfunction In Deceleration Sensor; Deceleration Sensor Circuit; Malfunction In Deceleration Sensor: Wiring Diagram

Fig 1: Deceleration Sensor Does Not Function - Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
