Spark Plugs (G2299463): Removal

NOTE:
  • This procedure contains illustrations showing certain components removed to provide extra clarity.
  • This procedure contains some variation in the illustrations depending on the vehicle specification, but the essential information is always correct.
  1. Remove the engine cover.

    Refer to: ENGINE COVER - INGENIUM I4 2.0L PETROL .

  2. G14451618Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

    Disconnect the electrical connector.

  3. G14451619Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
    • Disconnect the electrical connectors.
    • Remove the bolts.
    • Remove the ignition coil-on-plugs.
  4. G14451623Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

    Using the special tool, remove the spark plugs.

    Special Tool(s): 303-1450
