Instrument Panel Cluster - Virtual Display
| ITEM | DESCRIPTION |
|---|---|
| 1 | Speedometer |
| 2 | Message center |
| 3 | Tachometer |
| 4 | Engine coolant temperature gauge |
| 5 | Fuel gauge |
The IPC comprises a 12.3 inch HD TFT with a multilayered virtual display. The IPC has a high level of graphic presentation and interactive functionality. These features give the driver advanced levels of control and set-up using interactive graphic menu features.
The IPC combines a virtual representation of virtual analog instruments, graphic information, digital information and warning signals.
The virtual instrument panel can be configured using the steering wheel controls to meet personal preference.
The following options are available:
- 2 dial - Display the speedometer and power gauge either side of the information panel.
- 1 dial - Display 2 information panels either side of a central power gauge.
- Full map - Display the navigation system information over the entire instrument panel.
- Media - Display the current media source information over the entire instrument panel.
- Driver assistance - Display the current enabled driver assistance features over the entire instrument panel.
