Variable Camshaft Timing Solenoid (G2417308): Installation

WARNING: This page is about a different variant/trim than selected.

NOTE: Repeat this step for the other side.

Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

Apply clean engine oil to the mating face.

Refer to: SPECIFICATIONS
- Install 2 new O-ring seals.
  Renew Part: Variable Camshaft Timing (VCT) solenoid O-ring seals Quantity: 2 .
- Install the 2 variable valve timing solenoids.
- Install and tighten the 4 bolts.
  Torque : 9 Nm
- Install the wiring harness bracket.
- Install a new cable tie.
- Connect the 3 electrical connectors.
- Install the Noise, Vibration and Harshness (NVH) material.
- Install the 2 clips.
Install the charge air cooler.
Refer to: CHARGE AIR COOLER SERVICE POSITION
Connect the startup battery ground cable.
Refer to: 12V SYSTEM DISCONNECT AND CONNECT
