Electric Supercharger Bypass Valve

WARNING: This page is about a different variant/trim than selected.
G14066817Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

The electric supercharger bypass valve is installed on the charge air cooler. The electric supercharger bypass valve bypasses the intake air from the turbocharger to the charge air cooler.

The PCM  controls the electric supercharger bypass valve through PWM  signal.

For additional information, refer to: INTAKE AIR DISTRIBUTION AND FILTERING
