Auto Stop/Start Warning Indicator

WARNING: This page is about a different variant/trim than selected.

To illuminate the auto stop/start warning indicator, the PCM sends signals to the BCM /GWM through the FlexRay. The BCM /GWM transmits the message to the IPC through the HS CAN HMI systems bus.

Auto Stop/Start Warning Indicator - System Active

Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

The auto stop/start warning indicator illuminates green when the engine stops during an auto stop/start cycle, then extinguishes when the engine restarts.

Auto Stop/Start Warning Indicator - System Disabled

Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

The auto stop/start warning indicator illuminates white when the auto stop/start system is disabled.

Auto Stop/Start Warning Indicator - System Inhibit

Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

The auto stop/start warning indicator illuminates white when the auto stop/start system is active but a vehicle system requires the engine to run.
