Auto Stop/Start Switch
WARNING: This page is about a different variant/trim than selected.
The auto stop/start switch soft key is located in the ICP with touchscreen, which is located in the center of the instrument panel. The auto stop/start switch soft key can be accessed on the ICP with touchscreen. When the driver enables or disables the auto stop/start system, the request is transmitted from the ICP with touchscreen to the BCM /GWM . The request message is transmitted through the HS CAN Human Machine Interface (HMI) systems bus.
