Component Location - 1 Of 2

G14451559Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
ITEM DESCRIPTION
1 Brake vacuum sensor
2 Powertrain Control Module (PCM)
4 Crankshaft Position (CKP) sensor
5 Starter motor
