Crankshaft Front Seal - Vehicles With: MHEV (G2298799): Removal

NOTE:

This procedure contains illustrations showing certain components removed to provide extra clarity.
This procedure contains some variation in the illustrations depending on the vehicle specification, but the essential information is always correct.

Disconnect the startup battery ground cable.
Refer to: 12V SYSTEM DISCONNECT .
Raise and support the vehicle on a suitable 2 post lift.
Refer to: JACKING AND LIFTING .
Remove the crankshaft pulley.
Refer to: CRANKSHAFT PULLEY - VEHICLES WITH: MHEV .
Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
- Install the special tool.
  Special Tool(s): JLR-303-1628
- Rotate the special tool 35 degrees in a counter clockwise direction.
- Use the special tool to remove the crankshaft front seal.
- Discard the crankshaft front seal.
