Seatbelt Pretensioners
| Item | Description |
|---|---|
| 1 | Front seatbelt retractor and pretensioner - all except NAS passenger |
| 2 | Front seatbelt retractor and pretensioner with load limiter - NAS passenger only |
| 3 | Rear seatbelt retractor and pretensioner |
| 4 | Active seatbelt retractor and pretensioner - all, except NAS passenger |
| 5 | Driver seatbelt pretensioner |
| 6 | Active seatbelt retractor and pretensioner with load limiter - NAS passenger only |
A pyrotechnic pretensioner is integrated into each seatbelt retractor and, in some markets, the anchor point of the driver seatbelt. The pretensioners are used to tighten the seatbelts during a collision to ensure the occupants are securely held in their seats.
When operated by the RCM, the pretensioners rotate the spool holding the end of the webbing to tighten the seatbelt.
