Pressure Pad

G11704805Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

The pressure pad is a silicone filled bladder, with a hose connecting it to the Occupant Classification Sensor Control Module (OCSCM). Any load on the pressure pad is detected by the OCSCM.
