Instrument Cluster (Ic) Indications

You can display the recommended and the actual tire pressures in the IC message center as well as changing the pressure units (KPa, PSI or bar) and you can select light or heavy load in the Vehicle Info and Tire Pressure Check Instrument panel menus.

The warning indications to the driver are common on all vehicles fitted with TPMS. Warnings are conveyed by an amber warning indicator together with a text message, a supporting graphic, or both of these which appear in the message center.

The warning indicator and message center are driven by Controller Area Nework (CAN) messages from the Tire Pressure Monitoring Control Module (TPMCM). The warning indicator is illuminated by the cluster software continuously when the tire pressure is low and will flash for 75 seconds in the case of a sensor failure or a system fault.
