Removal And Installation: Removal
WARNING: This page is about a different variant/trim than selected.
NOTE:
- Removal steps in this procedure may contain installation details.
- Some variation in the illustrations may occur, but the essential information is always correct.
- Remove the battery ground cable.
Refer to: BATTERY AND CABLES
-
WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
- Remove the exhaust system.
Refer to: EXHAUST SYSTEM
- Remove the starter motor.
Refer to: STARTER MOTOR
-
CAUTION: Use a wooden block to protect the oil pan when supporting the engine.
