Removal And Installation: Installation

WARNING: This page is about a different variant/trim than selected.

Install the engine mount.
Torque Specifications:

Stage 1: 45 Nm

Stage 2: 60°
Fig 1: Left Engine Mount Bolts
Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

Torque Specification: 32 Nm
Torque Specification: 110 Nm
Torque Specification: 30 Nm
- Renew Part: Steering column lower shaft lower bolt Quantity: 1 .
- Torque Specification: 30 Nm
Install the front driveshaft.
Refer to: FRONT DRIVESHAFT - V6 S/C 3.0L PETROL/V8 S/C 5.0L PETROL
Install the exhaust system.
Refer to: EXHAUST SYSTEM
Connect the battery ground cable.
Refer to: SPECIFICATIONS
