Engine (Removal): Removal: Part(S)
WARNING: This page is about a different variant/trim than selected.
| STEP | PART NAME | QUANTITY |
|---|---|---|
| Step 9 | Steering column lower shaft lower bolt | 1 |
NOTE:
Some variation in the illustrations may occur, but the essential information is always correct.
- Disconnect the battery ground cable.
Refer to: SPECIFICATIONS
-
WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
- Refer to: SECONDARY BULKHEAD CENTRE PANEL - V6 S/C 3.0L PETROL
- Refer to: HOOD
- Refer to: RADIATOR
- Refer to: ENGINE OIL DRAINING AND FILLING
- Refer to: TRANSMISSION - V6 S/C 3.0L PETROL (REMOVAL)
-
NOTE: Left hand drive only.
Discard the bolt.
Renew Part: Steering column lower shaft lower bolt Quantity: 1 .
-
CAUTION: Before disconnecting any components, make sure the area is clean and free from foreign material. When disconnected all openings must be sealed.
-
WARNING: Do not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable vapors are always present and may ignite. Failure to follow these instructions may result in personal injury.CAUTION: Be prepared to collect escaping fuel.
-
CAUTION: Be prepared to collect escaping coolant.
-
CAUTION: Be prepared to collect escaping coolant.
-
CAUTION: Be prepared to collect escaping coolant.
-
CAUTION: Be prepared to collect escaping coolant.
-
NOTE: Using a suitable tie strap, secure the A/C compressor.
-
CAUTION: Be prepared to collect escaping coolant.
Special Tool(s): 303-1435
Torque Specification: 25 Nm
Special Tool(s): 303-1436
Torque Specification: 25 Nm
-
NOTE: This step requires the aid of another technician.
