Good

• If the DTC erase, substitute with a known-good unit and check for proper operation. If the problem is corrected, replace the unit and go to "Verification Of Repair " procedure.
• Repair as necessary and go to "Verification Of Repair " procedure.

No Good

• Repair as necessary and then go to "Verification Of Repair " procedure.
