Repair Procedures: Installation
WARNING: This page is about a different variant/trim than selected.
NOTE:
- Install the ECTS with the specified torque.
- If ECTS is dropped, it may cause internal damage. Do not use it.
- Apply the engine coolant to the O-ring (A).
 Courtesy of KIA MOTORS AMERICA, INC.
|
- The sensor fixing clip (A) must be replaced with a new one (Do not reuse.)
 Courtesy of KIA MOTORS AMERICA, INC.
|
- Install in the reverse order of removal.
- Fill the engine cooling system with coolant.
(Refer to Engine Mechanical System - "COOLANT
")
