Circuit Inspection

WARNING: This page is about a different car, the 2024 Kia Sorento. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of KIA MOTORS AMERICA, INC.

Courtesy of KIA MOTORS AMERICA, INC.

Courtesy of KIA MOTORS AMERICA, INC.

Courtesy of KIA MOTORS AMERICA, INC.

Courtesy of KIA MOTORS AMERICA, INC.

Good

• Go to "Component Inspection" procedure.

No Good

• Repair open or short in circuit and then go to ("Verification Of Repair r")procedure.

• Check module circuit for open circuit or short circuit after repair, go to ("Verification Of Repair ").
