Front Fog Lamp

WARNING: This page is about a different car, the 2024 Kia Sorento. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative (-) battery terminal.

    (Refer to Engine Electrical System - "AUXILIARY BATTERY ")

  2. Remove the front bumper assembly.

    (Refer to Body - "FRONT BUMPER ASSEMBLY ")

  3. Remove the front fog lamp assembly (A) by removing the mounting screws.
    G14958462Courtesy of KIA MOTORS AMERICA, INC.
