System Inspection
Good
- Disconnect M-CAN communication units one by one and monitor DTC to find the cause.
- If the DTC erase, substitute with a known-good unit and check for proper operation. If the problem is corrected, replace the unit and go to "VERIFICATION OF REPAIR " procedure.
No Good
- Check for open, short to battery and short to ground in M-CAN line.
- Repair as necessary and go to "VERIFICATION OF REPAIR " procedure.
