Repair Procedures: Inspection: Notes

Check point (Warning indicator)

NOTE:

Fault conditions and normal operating conditions, refer to the owner's manual.

NO	Ref Symbol	Name	Color	Signal Input	Signal Control	Check Point
1	Courtesy of KIA MOTORS AMERICA, INC.	Turnsignal (Left)	Green	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
2	Courtesy of KIA MOTORS AMERICA, INC.	Turnsignal (Right)	Green	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
3	Courtesy of KIA MOTORS AMERICA, INC.	Tail Lamp	Green	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
4	Courtesy of KIA MOTORS AMERICA, INC.	Front Fog Lamp	Green	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
5	Courtesy of KIA MOTORS AMERICA, INC.	Rear Fog Lamp	Yellow	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
6	Courtesy of KIA MOTORS AMERICA, INC.	Low Beam	Green	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
7	Courtesy of KIA MOTORS AMERICA, INC.	High Beam	Blue	CAN	BCM (Gateway)	Multifunction Switch BCM CAN Failure
8	Courtesy of KIA MOTORS AMERICA, INC.	Master Symbol	Yellow	CAN	BSD	BSD System CAN Failure
					TPMS	TPMS System CAN Failure
					BCM	External lamps BCM CAN Failure
					Fuel Sender	Fuel Sender Failure Wiring Failure
				Hard-wired	Low Washer	Washer fluid lever sensor Wiring Failure
				Hard-wired	Digital Input	Reminders when service checks
9	Courtesy of KIA MOTORS AMERICA, INC.	Battery Charge	Red	CAN	ECM	Charging System CAN Failure
10	Courtesy of KIA MOTORS AMERICA, INC.	Oil Pressure	Red	Hard-wired	ECM	ECM System Hard-wired CAN Failure
11	Courtesy of KIA MOTORS AMERICA, INC.	Check Engine	Yellow	CAN	ECM	ECM System CAN Failure
12	Courtesy of KIA MOTORS AMERICA, INC.	Immobilizer	Yellow	CAN	BCM (Gateway)	SMK System BCM CAN Failure Hard-wired
13	Courtesy of KIA MOTORS AMERICA, INC.	Parking Brake Brake Fluid EBD EPB	Red	CAN	BCM (Gateway) EBD EPB ABS TCS	BCM ABS System EPB System CAN Failure Parking Brake Switch Brake Oil Lever Sensor
14	Courtesy of KIA MOTORS AMERICA, INC.	ABS	Yellow	CAN	ABS	ABS System CAN Failure
15	Courtesy of KIA MOTORS AMERICA, INC.	ESC	Yellow	CAN	TCS	ABS System CAN Failure
16	Courtesy of KIA MOTORS AMERICA, INC.	ESC Off	Yellow	CAN	TCS	ABS System CAN Failure
17	Courtesy of KIA MOTORS AMERICA, INC.	Auto Hold	White Yellow Green	CAN	TCS	TCS System CAN Failure
18	Courtesy of KIA MOTORS AMERICA, INC.	Seat Belt	Red	CAN	BCM (Gateway)	BCM CAN Failure
19	Courtesy of KIA MOTORS AMERICA, INC.	Airbag	Red	CAN	SRSCM	SRSCM System CAN Failure
20	Courtesy of KIA MOTORS AMERICA, INC.	EPS (MDPS)	Red	CAN	MDPS	MDPS Unit System MDPS Motor CAN Failure
21	Courtesy of KIA MOTORS AMERICA, INC.	TPMS	Yellow	CAN	TPMS	TPMS System TPMS Sensor CAN Failure
22	Courtesy of KIA MOTORS AMERICA, INC.	LDWS	Green Yellow White	CAN	LDWS	LDWS System CAN Failure
23	Courtesy of KIA MOTORS AMERICA, INC.	Fuel Warning	Yellow	Direct (Micom)	Fuel Segment	Fuel Sender Failure Wiring Failure
24	Courtesy of KIA MOTORS AMERICA, INC.	Door Open	Red	CAN	BCM (Gateway)	BCM CAN Failure Door Sensor/switch
25	Courtesy of KIA MOTORS AMERICA, INC.	ECO	Green	Hard-wired	ECO mode	ECM System CAN Failure
26	Courtesy of KIA MOTORS AMERICA, INC.	SPORT	Yellow	Hard-wired	SPORT mode	ECM System CAN Failure
27	Courtesy of KIA MOTORS AMERICA, INC.	CRUISE	Green	CAN	ECM	ECM System CAN Failure
28	Courtesy of KIA MOTORS AMERICA, INC.	SET	Green	CAN	ECM	ECM System CAN Failure
29	Courtesy of KIA MOTORS AMERICA, INC.	Over speed	Yellow	CAN	ECM	ECM CAN Failure
30	Courtesy of KIA MOTORS AMERICA, INC.	AEB	Yellow	CAN	SCC	AEB System CAN Failure
31	Courtesy of KIA MOTORS AMERICA, INC.	Cooling water temperature	Red	CAN	EMS	EMS System CAN Failure
32	Courtesy of KIA MOTORS AMERICA, INC.	Diesel Particulate Filter (DPF)	Yellow	CAN	ECM	DPF System CAN Failure
33	Courtesy of KIA MOTORS AMERICA, INC.	Oil Level	Yellow	CAN	ECM	ECM CAN Failure
34	Courtesy of KIA MOTORS AMERICA, INC.	Water separator	Red	Hard-wired	Water separator sensor	Water separator sensor Wiring failure
35	Courtesy of KIA MOTORS AMERICA, INC.	AUTO STOP	Green Yellow	CAN	ECM	ECM CAN Failure
35	Courtesy of KIA MOTORS AMERICA, INC.	AUTO STOP	Green Yellow	CAN	ECM	ECM CAN Failure

Check point (Gauge)

NO	Name	Signal Input	Signal Control (Unit/Sensor)	Check Point
1	Speedometer	C-CAN	ABS/ESC	ABS System CAN Line failure
2	Tachometer	C-CAN	ECM	ECM CAN Line failure
3	Cooling water temperature	C-CAN	ECM	ECM CAN Line failure
4	Fuel	Hardwire	Fuel Sander	Fuel sender failure Wiring failure
