Repair Procedures: Inspection

Check point (Warning indicator)

NO	Ref Symbol	Color	Name	Signal Input	Signal Control (Unit/Sensor)	Check Point
1	Courtesy of KIA MOTORS AMERICA, INC.	Green	Turn Left	C-CAN	GWAY	CAN line failure
2	Courtesy of KIA MOTORS AMERICA, INC.	Green	Turn Right	C-CAN	GWAY	CAN line failure
3	Courtesy of KIA MOTORS AMERICA, INC.	Green	Front Fog	C-CAN	GWAY	CAN line failure
4	Courtesy of KIA MOTORS AMERICA, INC.	Blue	High Beam	C-CAN	GWAY	CAN line failure
5	Courtesy of KIA MOTORS AMERICA, INC.	Green	Low Beam	C-CAN	GWAY	CAN Line failure
6	Courtesy of KIA MOTORS AMERICA, INC.	Green	Tail Lamp	C-CAN	GWAY	CAN Line failure
7	Courtesy of KIA MOTORS AMERICA, INC.	Green	Cruise	C-CAN	VCU	CAN line failure
8	Courtesy of KIA MOTORS AMERICA, INC.	Green	SET	C-CAN	GWAY	CAN line failure
9	Courtesy of KIA MOTORS AMERICA, INC.	Red	Seat Belt	C-CAN	GWAY	CAN line failure
10	Courtesy of KIA MOTORS AMERICA, INC.	Red	Air Bag	C-CAN	ACU	CAN line failure
11	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	Trunk Open	C-CAN	GWAY	CAN line failure
12	Courtesy of KIA MOTORS AMERICA, INC.	Red	Door Open	C-CAN	BGWAY	CAN line failure
13	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	Immobilizer	C-CAN	GWAY	CAN line failure Wiring failure
14	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	ABS	C-CAN	ESC	CAN line failure
15	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	ESC	C-CAN	TCS	CAN line failure
16	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	ESC OFF	C-CAN	TCS	CAN line failure
17	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	TPMS	C-CAN	TPMS	CAN line failure
18	Courtesy of KIA MOTORS AMERICA, INC.	Red	Parking Brake	C-CAN	GWAY TCS AHB	CAN line failure
19	Courtesy of KIA MOTORS AMERICA, INC.	Red	Battery Charge	C-CAN	LDC	Wiring failure
20	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	Check Engine	C-CAN	EMS	CAN line failure
21	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	Low Washer	Hardwire	Water Level Sensor	Wiring failure
22	Courtesy of KIA MOTORS AMERICA, INC.	Green	Active ECO	C-CAN	VCU	CAN line failure Wiring failure
23	Courtesy of KIA MOTORS AMERICA, INC.	Red	MDPS	C-CAN	MDPS	MDPS unit failure CAN line failure
24	Courtesy of KIA MOTORS AMERICA, INC.	Green	READY	C-CAN	VCU	CAN line failure
25	Courtesy of KIA MOTORS AMERICA, INC.	Green	EV battery charge	Hardwire+C-CAN	BMS	CAN line failure Wiring failure
25	Courtesy of KIA MOTORS AMERICA, INC.	Red	EV battery charge	Hardwire+C-CAN	EMS	CAN line failure
26	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	EV System	C-CAN	VCU, MCU, BMS, LDC, FACT, OBC	CAN line failure
27	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	Power Down	C-CAN	VCU	CAN line failure
28	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	RBS	C-CAN	EBS	CAN line failure
29	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	Low Power	C-CAN	VCU	CAN line failure
30	Courtesy of KIA MOTORS AMERICA, INC.	Yellow	EPB	C-CAN	EPB	CAN line failure

Check point (Gauge)

No.	Name	Signal Input	Signal Control (Unit/Sensor)	Check Point
1	Speedometer	C-CAN	MCU	CAN Line failure
2	SOC Gauge	C-CAN	BMS	CAN Line failure
3	Power and Charge Gauge	C-CAN	VCU	CAN Line failure

Check the specified value of cluster connector in specified condition.

No.	Description	Input/Output	Communication	Value (V)	Specified Conditions
1	GND_Signal3	Input	Hardware	Above 5V	IGN switch ON,
2	ILL (-)_OUT-	Output	Hardware	Below 1V	IGN switch ON, Tail switch ON, Rheostat Max
2	ILL (-)_OUT-	Output	Hardware	9~16V	IGN switch ON, Tail switch ON, Rheostat Min
3	RheostatSWDown_IN	Input	Hardware	Below 1.5V	Rheostat switch down button push
4	RheostatSWUp_IN	Input	Hardware	Below 1.5V	Rheostat switch up button push
5	Detent_OUT+	Output	Hardware	9~16V	IGN switch ON, Rheostat Max
6	P_OUT+	Output	Hardware	9~16V	IGN On, P position
7	R_OUT+	Output	Hardware	9~16V	IGN On, R position
8	N_OUT+	Output	Hardware	9~16V	IGN On, N position
9	D_OUT+	Output	Hardware	9~16V	IGN On, D position
10	B_OUT+	Output	Hardware	9~16V	IGN On, B position
11	ALTL_OUT	Output	Hardware
12	-	-	-	-	-
13	-	-	-	-	-
14	-	-	-	-	-
15	AirBag (+)_IN	Output	Hardware	Above 5V	IGN switch ON
16	-	-	-	-	-
17	-	-	-	-	-
18	SPEED_OUT-	Input	Hardware	9~16V	IGN switch ON/Vehicle speed over 1 km/h
19	IGN3	Input	Hardware	Above 9V	Battery charge
20	TailLamp_IN	Input	Hardware	9~16V	Tail switch On
21	TripSW (-)_IN	Input	Hardware	Below 1V	Always
22	TripSW1 (+)_IN	Output	Hardware	0.56~5V	IGN ON, Push Trip button
23	TripSW2 (+)_IN	Output	Hardware	0.56~5V	IGN ON, Push Trip button
24	-	-	-	-	-
25	-	-	-	-	-
26	LowWasherLevel_IN-	Output	Hardware	9~16V	IGN switch ON
26	LowWasherLevel_IN-	Output	Hardware	Below 1V	Washer level low
27	-	-	-	-	-
28	HeatedWheelIND_IN	Output	Hardware	9~16V	IGN switch On
28	HeatedWheelIND_IN	Output	Hardware	Below 1V	Heated wheel switch Push
29	MM_CAN_Low	Input	CAN	-	-
30	MM_CAN_High	Input	CAN	-	-
31	-	-	-	-	-
32	C_CAN_High	Input	CAN	-	-
33	C_CAN_Low	Input	CAN	-	-
34	-	-	-	-	-
35	-	-	-	-	-
36	-	-	-	-	-
37	GND_Signal1	Input	Hardware	Below 1V	Always
38	-	-	-	-	-
39	IGN1	Input	Hardware	9~16V	IGN switch ON
40	B+	Input	Hardware	9~16V	Always
