Terminal and Connector Inspection
- Many malfunctions in the electrical system are caused by poor connection. Faults can also be caused by interference from other electrical system and mechanical or chemical damage.
- Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
- Has a problem been found?
YES
- Repair as necessary and go to "Verification of Vehicle Repair " procedure.
NO
- Go to "Squib Circuit Inspection " procedure.
