Instrument Cluster Speaker

  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad center lower panel.

    (Refer to Body - "CRASH PAD CENTER PANEL ")

  3. Disconnect the instrument cluster speaker connector (A).
  4. Remove the instrument cluster speaker (B) after loosening the mounting nuts.
Fig 1: Removing Instrument Cluster Speaker Mounting Nuts
G12334722Courtesy of KIA MOTORS AMERICA, INC.
