Repair Procedures: Inspection: [Rotor]

WARNING: This page is about a different variant/trim than selected.

Check that there is continuity between the slip rings (C).

Fig 1: Locating Slip Rings, Rotor And Shaft
Courtesy of KIA MOTORS AMERICA, INC.
Check that there is no continuity between the slip rings and the rotor (B) or rotor shaft (A).
If the rotor fails either continuity check, replace the alternator.
