Terminal and Connector Inspection

Many malfunctions in the electrical system are caused by poor harness and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage.
Has a problem been found?

Fig 1: Body Control Module, Smart Key Module And Wireless Power Charger Circuit Diagram
Courtesy of KIA MOTORS AMERICA, INC.

Fig 2: Body Control Module, Smart Key Module And Wireless Power Charger Connector Terminals
Courtesy of KIA MOTORS AMERICA, INC.

YES
- Repair open or short circuit and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.
NO
- If no problems were found with the circuits or connectors, replace WPC and go to "VERIFICATION OF VEHICLE REPAIR " procedure.
