DTC B2523-00: Turn Signal LH Rear SCG: General Description

Once BCM receives right turn switch working signal, it sends the signal to SJB by CAN communication. SJB makes right turn signal lamp flickering.

Fig 1: BCM CAN Communication Diagram (Right Turn Switch)

Courtesy of KIA MOTORS AMERICA, INC.
